Double Dome LED OT Light
LED-OT-Light Manufacturer

Rio Series

Double Dome LED OT Light

The RIO Series Surgical LED OT Light is designed to deliver high-intensity, shadowless illumination for enhanced visibility during surgical procedures. Featuring adjustable colour temperature, Endo Mode, memory function, and a sterilizable handle, it provides precise lighting control and reliable performance. Its advanced design supports effective shadow compensation, adjustable light focus, and smooth positioning through a 360° rotating arm.

Adjustable Colour Temperature
Shadow Compensation
Memory Function & Endo Mode
360° Rotating Arm
Categories: , ,

Equipped With Advanced Features

Adjustable Colour Temperature

RIO LED lights are capable of producing a wide range of color temperatures between 4000-5000 K, allowing users to adjust the lighting to suit different purposes, environments, and preferences.

Adjustable color temperature allows surgeons to fine-tune the lighting to match their specific needs for different procedures.

Adjustable Colour Temperature

Supramaximal effective light field

With high light intensity and large spot size, 1200mm depth of field provides good lighting without having to refocus when the surgical wound location changes.

The light head can be positioned far away from the wound to ensure better laminar flow.

Supramaximal effective light field

Komax Series Features

High-quality bearing

High-quality bearing

High quality bearing to ensure no drift and flexible rotation

ISO standard base plate

ISO standard base plate

High strength integrated aluminium forming.

High-strength aluminum

High-strength aluminum

Seamless welding ensures each arm supports a load of up to 80 kg.

Shadow compensation

Shadow compensation

Intelligent shadow compensation automatically increases LED brightness in unobstructed areas to maintain consistent surgical field illumination.

Sterilizable handle

Sterilizable handle

The sterilizable handle withstands autoclaving or chemical sterilization, ensuring easy cleaning and maintaining infection control.

Focusing System

Focusing System

The brightness of different LEDs is adjustable to change the spot size, which will avoid the possible occurrence of mechanical malfunctions.

Endo Mode

Endo Mode

Endo Mode reduces surgical LED light intensity to enhance endoscopic image contrast and visibility.

Touchscreen control panel

Touchscreen control panel

Features include illumination intensity and colour temperature adjustment, Endo Mode, memory function, and power on/off control.

Meets modern laminar flow

Meets modern laminar flow OR requirements

The open-design light minimizes airflow obstruction, reducing turbulence beneath air-supply ceilings.

Technical Specifications

Explore the advanced features, illumination performance, and technical specifications of the Rio Series LED Surgical Light

Model Rio 6+6 Rio 5+5 Rio 4+4 Rio 3+3
Installation Double Dome Double Dome Double Dome Double Dome
Intensity 1,60,000 + 1,60,000 ±10% 1,40,000 + 1,40,000 ±10% 1,30,000 + 1,30,000 ±10% 1,00,000 + 1,00,000 ±10%
Number of LED 126 + 126 105 + 105 84 + 84 63 + 63
Size of Light Field 12-30 cm 12-30 cm 12-30 cm 12-30 cm
Colour Temperature 4000-5000 K 4000-5000 K 4000-5000 K 4000-5000 K
Colour Rendering Index 93 RA 93 RA 93 RA 93 RA
Colour Temperature 4000-5000 K 4000-5000 K 4000-5000 K 4000-5000 K
Intensity Control 10 step 10 step 10 step 10 step
CRI (Ra) 95 95 95 95
LED Life >50000 Hrs. >50000 Hrs. >50000 Hrs. >50000 Hrs.
Diameter of Light 650mm 650mm 650mm 650mm
Dimming Range 10%-100% 10%-100% 10%-100% 10%-100%
Brightness Control Capacitive Touch Panel Capacitive Touch Panel Capacitive Touch Panel Capacitive Touch Panel
Power Supply 220V/50Hz AC 220V/50Hz AC 220V/50Hz AC 220V/50Hz AC
Colour of LED White & Yellow (Double Colour) White & Yellow (Double Colour) White & Yellow (Double Colour) White & Yellow (Double Colour)
Focusing Adjustable Adjustable Adjustable Adjustable
Monitor / Camera / Wireless Wall Controller Optional Optional Optional Optional

Double Dome LED OT Lights — Other Configurations

Model Rio 6+5 Rio 6+4 Rio 6+3 Rio 5+4 Rio 5+3 Rio 4+3
Installation Double Dome Double Dome Double Dome Double Dome Double Dome Double Dome
Intensity 1,60,000 + 1,40,000 ±10% 1,60,000 + 1,30,000 ±10% 1,60,000 + 1,00,000 ±10% 1,40,000 + 1,30,000 ±10% 1,40,000 + 1,00,000 ±10% 1,30,000 + 1,00,000 ±10%
Number of LED 126 + 105 126 + 84 126 + 63 105 + 84 105 + 63 84 + 63

Frequently Asked Questions

Key features include adjustable illumination intensity, colour temperature adjustment, Endo Mode, memory function, and a sterilizable handle.

Endo Mode reduces the overall light intensity to support endoscopic procedures by improving the contrast and visibility of endoscopic images.

Yes, the memory function allows users to recall saved lighting settings for convenient operation.

Yes, the sterilizable handle is designed to withstand suitable sterilization processes, supporting easy cleaning and infection control.

Yes, users can adjust illumination intensity according to procedural requirements.

Yes, colour temperature adjustment allows users to customize the light appearance to suit their preferences and procedural needs.
